Channel Number 2 (1 Stereo Pair)
Power (W / Channel) | 4 ohms 150 W
Power (W / Channel) | 8 ohms 100 W
Power (W / Channel) | Bridge (8 ohms) 320 W (1CH)
Input Impedance 20 K ohms
Output Impedance (Loop RCA) 600 ohms
Input Sensitivity 100 mV / 1 W, 1000 mV – Full power
Maximum Input Voltage 2.9 V
Signal to Noise (SN:R) -100 dB (20 Hz – 20 kHz)
Frequency Response 5 Hz – 50 kHz
Total Harmonic Distortion THD + N@1 KHz 0.03%
Rack Height 1U
Dimensions (Excluding Feet (H x W x D)) 42.4 x 438 x 427 mm
Dimensions (Including Feet (H x W x D)) 52.8 x 438 x 427 mm
Width (including rack brackets) 482 mm (19")
Weight 5.29 kg (11 lb 10 oz)
Mains Operating Voltage
100 – 120 V @ 60 Hz
220 – 240 V @ 50 Hz
Fuse Type 5 A (T5AL ~ 250VAC)
Standby Power Consumption <0.5 W (green mode)
Channel Number
2 (1 Stereo Pair)
Power (W / Channel) | 4 ohms
150 W
Power (W / Channel) | 8 ohms
100 W
Power (W / Channel) | Bridge (8 ohms)
320 W (1CH)
Power (W / Channel) | 70V
N/A
Input Impedance
20 K ohms
Output Impedance (Loop RCA)
600 ohms
Input Sensitivity
100 mV / 1 W, 1000 mV – Full power
Maximum Input Voltage
2.9 V
Signal to Noise (SN:R)
-100 dB (20 Hz – 20 kHz)
Frequency Response
5 Hz – 50 kHz
Total Harmonic Distortion THD + N@1 KHz
0.03%
Dimensions (Excluding Feet (H x W x D))
42.4 x 438 x 427 mm (111/16x 171/4 x 16 13/16")
Dimensions (Including Feet (H x W x D))
52.8 x 438 x 427 mm (21/16x 171/4 x 1613/16")
Width (including rack brackets)
482 mm (19")
Weight
5.29 kg (11 lb 10 oz)
Mains Operating Voltage
100 – 120 V @ 60 Hz
220 – 240 V @ 50 Hz
Fuse Type
5 A (T5AL ~ 250VAC)
Standby Power Consumption
<0.5 W (green mode)
Networked Standby Power Consumption
N/A
